Our extensive product offering and customizing capabilities make us an ideal partner providing tailored motion platforms for your R&D.

Our products make a difference:

From small PORTABLE DESKTOP to large multi m³ MOTION PLATFORMS
UNMATCHED DYNANIC PERFORMANCE ideal for tracking or motion simulation applications
POWERFUL REALTIME CONTROL SYSTEM, easy to use under MS WINDOWS
EASY TO INTEGRATE with MATLAB, Simulink, LabVIEW..
SCALABLE HARD & SOFTWARE supporting simple and highly complex applications
SCIENTIFIC TOOLBOX contains powerful diagnostic and analytic tools, a set of advanced motion commands and tools to create your own algorithms
FLEXIBLE ULTRA PRECISION REALTIME EVENT SYNCHRONIZATION
POWERFUL 3D- ERRORMAPPING CAPABILITIES

AEROSPACE

ADVANCED TECHNOLGIES FOR AEROSPACE APPLICATIONS

High load systems with long travel for calibration of sensors:

Linear stage load capacity up to 1000kg
Long travel stages and gantries with up to 4600mm

Synchronization GPS signals with the position:

High resolution signal sampling at a rate of 100kHz
Latch position based on time, external trigger or GPS signal

MOTION SYSTEMS FOR MOTION OF MIRRORS AND TRACKING APPLICATIONS

Gimbal systems with limited or unlimited travel

Multi Axes Motion systems for small- to large-scale optics
Precision Tracking of ultra-slow to ultra-fast and dynamic motion
Ultra-high resolution
Different environments including vacuum
Custom assemblies for virtually any kind of optics

Flexible mounting options:

Custom mounting interface
Support a large variety of sizes and inertias

BEAMLINES

MOTION SYSTEMS FOR SAMPLE MANIPULATION

Broad variety of Rotary stages with outstanding error motion characteristics:

Rotation of the sample with excellent error motion
Clear Apertures from 10mm to 500mm diameter
High speed direct driven rotary stages
Slip rings and rotary unions available
Small alignment stages on the rotary stage and be added

Alignment stacks for the assembly:

XYZ and tilt alignment for the complete setup
Complex setup for the best and easy to use alignment application for sample to beam and sample to detector alignment

Guaranteed specifications including sphere of confusion

Extensive measurement capabilities:

We verify system level specifications in our Precision Measurement Lab and prove what we promise in terms of static and dynamic motion and alignment specifications
Single axis to 3D error measurement and calibration

Control system: Easy to adapt – easy to integrate

Beamlines can work with their controller and software interface
Easy and quick optimization of the PID loop controller when changing the sample
Outstanding picometer level position stability

DEFENSE R&D

DEVELOPMENT AND CALIBRATION OF MILITARY TECHNOLGY

Calibration of sensors for missiles:

Target- and UUT (Unit Under Test) system for sensor head from missiles development
High resolution high dynamic motion systems to analyze UUT or DUT performance
Completely assembled, tested and calibrated systems

Tracking of moving objects:

3 DOF gimbal systems to track moving and flying objects
Linear stages for motion of any kind of targets with high dynamic performance

One to three axes motion simulators for Sensor testing

Analyze Sensor signals

Custom high bandwidth one- to three axes rotation systems for high dynamic performance or ultra smooth motion
Integrated standard and optional slip rings High number of lines per slipring and low noise version available
Customized mechanical and electrical mounting interfaces Including customized cable management systems

A new level of performance achieved by ultra stiff servo control

100kHz position and velocity regulation set new standards in performance
50kHz trajectory streaming with optimized jerk planning

FUNDAMENTAL RESEARCH

Let`s team up, you know your experiment- we know motion

If motion is critical for your success we take that risk away from you.

Cooperation with Universities, government institutions and R&D centers:

Develop future technology
We support many different applications like laser processing, delay lines, lithography applications, additive manufacturing, etc.
Accuracy with sub-micron levels

Flexibility for different process environments

Standard Lab
Cleanroom applications with up to cleanroom class ISO5
Medium vacuum, high vacuum and ultra-high vacuum applications
Others

PROTOTPYES FOR R&D WITH HIGH ACCURACY

Multi axes assembly from a small scale up to high load:

Linear axes from 25mm to 4.600mm travel
Elevation axes from 25mm to 200mm vertical travel
Telescope axes from 100mm to 1.200mm travel
Gantries from 3.000mm by 4.600mm active work area

Set-up of the system with advanced controls:

Easy change of control parameters by changing the load
Automatic recalculation of compensation values when the work-point location and or temperature changes

LIFE SCIENCES

Boost efficiency and reliability in Life sciences Labs

Higher precision and throughput for ear implant manufacturing:

Boost motion performance at various levels of ear implants manufacturing
Laser welding, cutting and drilling applications
Multi-dimensional and spherical motion for laser applications

Advanced controller features for laser applications:

Realtime trigger for laser beam source based on the position of the sample
Improvement of the accuracy by real time triggers

High dynamic system for saving costs and high throughput

Pick and place applications with gantry systems:

From short to very long travel gantry systems (up to 4600mm travel) for pick and place applications with outstanding settling characteristics.
Direct drive linear motor technology of best dynamic performance

From components to fully Integrated systems:

Motion subsystem(s) mounted on machine base, complete mechanically and electrically integrated and tested. (Integration could include a machine-housing, object mounting adapters, handling systems, sensors, cameras and custom software.
